Soluna Battery Module EOS 5K LV Pack

Soluna Battery Module EOS 5K LV Pack

Soluna EOS 5K | Power Wall Battery


General Overview


The Soluna EOS 5K boasts a 51.2V LFP 5.12kWh pack with a lifespan of ≥6000 cycles at 90% DOD. It has an IP65 rating and comes with a 10-year warranty. Optional mounting options such as wall mount, floor mount, and rack mount are available. Choose from either white or black and feel confident knowing it is UL and IEC approved for added peace of mind. The Soluna Battery Module EOS 5K is a 48V battery solution designed for Residential and small Commercial energy storage applications. This model utilizes the latest LiFePO4 technology with an intelligent BMS built-in for blackout protection, providing a 5kWh capacity that can be installed in parallel with up to 12 batteries for a total storage of 60kWh.

Product Specifications:

Specifications
Dimensions (H x W x D) 595mm x 438mm x 165mm
Weight 60 kg
Installation Indoor/Outdoor/Wall/Floor/Rackmount
Battery Type Lithium LFP
Nominal Capacity 5.12 kWh
Nominal Voltage 51.2 V
Voltage range (usable) 40 to 58.4V
Max. charge/discharge current 100A
Depth of discharge (DoD) 90%
Internal resistance ≤60
Cycle life 6000
Battery pack round-trip efficiency >95%
DC disconnect Contactor Fuse
Power Consumption <3 W (work) <100mW (sleep)
Monitoring parameters System voltage System current Cell voltage Cell Temperature
Communication CAN-Wifi, RS 485
Operating temperature -10 to 50°C
Operating temperature (recommended) 15 to 30°C
Storage temperature (recommended) 15 to 30°C
Humidity conditions 5 to 95%
Altitude Max. 2000m
Cooling Strategy Natural Convection
Certification Cell UL1642 Battery module IEC62619 & UL1973
Ingress protection rating IP 65
System configuration 1 to 12 parallel
Product and performance 10-year standard warranty



Quick Specs

User Manual Download

Soluna EOS 5K Pack_User Manual
